- Code Machine
- FL1122
- Fabricant
- KBA FLEXOTECNICA
- Modello
- EVO XD
- Année
- 2017
- Number of colors
- 8
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1320
- Print width (mm)
- 1270
- Min print repeat (mm)
- 380
- Max print repeat (mm)
- 800
- Unwinder type
- Turret Automatic with roll loading system
- Rewinder type
- Turret Automatic with roll unloading system
- Drying
- 2 zones , 4 fans , final tunnel 5 mt length , 2 Gas Burners 200.000 Kcl/h each, Automatic Air recirculation system with LEL controls on each zone Zellweger
- Videocamera
- YES AVT 100% INSPECTION
- Web guides
- Yes in and out
- Vyscosity control
- yes GAMA
- Washing system
- Yes
- Anilox
- 12 ceramic anilox sleeves
- Print Sleeves
- approx 100
Code Machine | FL1122 |
Fabricant | KBA FLEXOTECNICA |
Modello | EVO XD |
Année | 2017 |
Number of colors | 8 |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1320 |
Print width (mm) | 1270 |
Min print repeat (mm) | 380 |
Max print repeat (mm) | 800 |
Unwinder type | Turret Automatic with roll loading system |
Rewinder type | Turret Automatic with roll unloading system |
Drying | 2 zones , 4 fans , final tunnel 5 mt length , 2 Gas Burners 200.000 Kcl/h each, Automatic Air recirculation system with LEL controls on each zone Zellweger |
Videocamera | YES AVT 100% INSPECTION |
Web guides | Yes in and out |
Vyscosity control | yes GAMA |
Washing system | Yes |
Anilox | 12 ceramic anilox sleeves |
Print Sleeves | approx 100 |
UTECO TOPAZ 608
-
Code Machine: FL0927
-
Année: 2010
-
Web width (mm): 1350
FLEXOTECNICA TACHYS
-
Code Machine: FL0995
-
Année: 2000
-
Web width (mm): 950
FISCHER & KRECKE F16 S
-
Code Machine: FL1086
-
Année: 2002
-
Web width (mm): 1150
PCMC VISION G
-
Code Machine: FL0715
-
Année: 2005
-
Web width (mm): 1000
FLEXOTECNICA TACHYS
-
Code Machine: FL1127
-
Année: 1998
-
Web width (mm): 850
UTECO DIAMOND HP 108
-
Code Machine: FL1012
-
Année: 2009
-
Web width (mm): 1350
