- Código Máquina
- ME72
- Constructor
- GALILEO
- Modello
- 1610 HR-V2
- Año
- 1998
- Working width (mm)
- 1620
- Materials
- Polyester film: 10 mic to 60 mic; BOPP film: 15 mic to 100 mic; CPP film: 25 mic to 80 mic; HDPE film: 20 mic to 120 mic
- Speed
- 720 m/min
- Max diameter reel unwinder
- 1000 mm
- Max diameter reel rewinder
- 1000 mm
- Evapouration Boots
- Number 19; size 120 x 35 x 10 mm
- Pumping system
- Metallization chamber: 2 x diffusion pumps 30.000 1/s, 1 x mechanical booster pump with variable speed motor 2.400 m3/h, 1 x cryogenic panel 150.000 1/s polycold PFC 1100-HC, 1 x pump with rotating piston 505 m3/h. Winding chamber: 1 x mechanical booster pump 13.000 m3/h, 1 x mechanical booster pump 5500 m3/h, 1 x mechanical booster pump 2000 m3/h, 1 x cryogenic panel 150.000 1/s polycold PFC 1100-HC, 2 x pumps with rotating piston 505 m3/h. Guard chamber: 1 x mechanical booster pump 2.00 m3/h, 1 x mechanical booster pump 1000 m3/h
- Polycold
- Cryogenic refrigeration unit model PFC - 1100 - HC; Design pressures: LOW (suction) side: 300 PSI (2070 KPA); HIGH (discharge) side: 400 PSI (2760 KPA); ELECTRICAL: Power supply: 400 - 3 - 50.
- Note
- Shaft 152mm Accesories: evaporative boats, aluminium wires, graphite film, drive belts, protective screens,
| Código Máquina | ME72 |
| Constructor | GALILEO |
| Modello | 1610 HR-V2 |
| Año | 1998 |
| Working width (mm) | 1620 |
| Materials | Polyester film: 10 mic to 60 mic; BOPP film: 15 mic to 100 mic; CPP film: 25 mic to 80 mic; HDPE film: 20 mic to 120 mic |
| Speed | 720 m/min |
| Max diameter reel unwinder | 1000 mm |
| Max diameter reel rewinder | 1000 mm |
| Evapouration Boots | Number 19; size 120 x 35 x 10 mm |
| Pumping system | Metallization chamber: 2 x diffusion pumps 30.000 1/s, 1 x mechanical booster pump with variable speed motor 2.400 m3/h, 1 x cryogenic panel 150.000 1/s polycold PFC 1100-HC, 1 x pump with rotating piston 505 m3/h. Winding chamber: 1 x mechanical booster pump 13.000 m3/h, 1 x mechanical booster pump 5500 m3/h, 1 x mechanical booster pump 2000 m3/h, 1 x cryogenic panel 150.000 1/s polycold PFC 1100-HC, 2 x pumps with rotating piston 505 m3/h. Guard chamber: 1 x mechanical booster pump 2.00 m3/h, 1 x mechanical booster pump 1000 m3/h |
| Polycold | Cryogenic refrigeration unit model PFC - 1100 - HC; Design pressures: LOW (suction) side: 300 PSI (2070 KPA); HIGH (discharge) side: 400 PSI (2760 KPA); ELECTRICAL: Power supply: 400 - 3 - 50. |
| Note | Shaft 152mm Accesories: evaporative boats, aluminium wires, graphite film, drive belts, protective screens, |
