- Código Máquina
- EC45
- Constructor
- S.A.M.
- Año
- 2011
- Width (mm)
- 1450
- Coating/lamination units
- 2 x extrusion coating lamination units, 2 x rotogravure coating unit with double extended driers
- Coating/lamination unit 1 description
- Gravure coating unit for primer with double drier 2 x 3 mt - 4 fans
- Coating/lamination unit 2 description
- Extrusion coating laminating unit with single extruder diam 90 - AC motor . Extrusion die Cloeren with 62 thermobolts , auto profile control and internal deckling Gravimetric dosing unit 4 comp MacGuire
- Coating/lamination unit 3 description
- Gravure coating unit for primer with double drier 2 x 3 mt - 4 fans
- Coating/lamination unit 4 description
- Extrusion coating laminating unit with coex three layer coextrusion coating lamination . Extrusion die Cloeren with 62 thermobolts , auto profile control and internal deckling Two Gravimetric dosing unit 4 comp MacGuire
- Treatment
- Corona treaters after unwinders 1 and 2
- Primary unwinder description
- Turret automatic bi-directional roll daim 1300 mm
- Secondary unwinder description
- Turret automatic bi-directional roll daim 1300 mm
- 3rd unwinder description
- Turret automatic bi-directional roll daim 1300 mm
- Rewinder description
- Turret automatic
- Speed
- 300 m/min
- Note
- 2 Corona Treater Mero , driven , ceramic Die Head Cloeren With Auto Thinckness Control 62 Screws Internal Deckling System Two New Thinkness Control Thermofischer 2 Spare Chill Roller Diam 1000 Both Un Its Also Laminating
| Código Máquina | EC45 |
| Constructor | S.A.M. |
| Año | 2011 |
| Width (mm) | 1450 |
| Coating/lamination units | 2 x extrusion coating lamination units, 2 x rotogravure coating unit with double extended driers |
| Coating/lamination unit 1 description | Gravure coating unit for primer with double drier 2 x 3 mt - 4 fans |
| Coating/lamination unit 2 description | Extrusion coating laminating unit with single extruder diam 90 - AC motor . Extrusion die Cloeren with 62 thermobolts , auto profile control and internal deckling Gravimetric dosing unit 4 comp MacGuire |
| Coating/lamination unit 3 description | Gravure coating unit for primer with double drier 2 x 3 mt - 4 fans |
| Coating/lamination unit 4 description | Extrusion coating laminating unit with coex three layer coextrusion coating lamination . Extrusion die Cloeren with 62 thermobolts , auto profile control and internal deckling Two Gravimetric dosing unit 4 comp MacGuire |
| Treatment | Corona treaters after unwinders 1 and 2 |
| Primary unwinder description | Turret automatic bi-directional roll daim 1300 mm |
| Secondary unwinder description | Turret automatic bi-directional roll daim 1300 mm |
| 3rd unwinder description | Turret automatic bi-directional roll daim 1300 mm |
| Rewinder description | Turret automatic |
| Speed | 300 m/min |
| Note | 2 Corona Treater Mero , driven , ceramic Die Head Cloeren With Auto Thinckness Control 62 Screws Internal Deckling System Two New Thinkness Control Thermofischer 2 Spare Chill Roller Diam 1000 Both Un Its Also Laminating |
KUHNE/ SML
-
Código Máquina: EC48
-
Año: 2006
-
Width (mm): 1180
HAN YOUNG Extrusion lamination
-
Código Máquina: EC32
-
Año: 2005
-
Width (mm): 2200
SML - STARLINGER
-
Código Máquina: EC40
-
Año: 2000
-
Width (mm): 1550
HAN YOUNG extrusion lamination
-
Código Máquina: EC31
-
Año: 2001
-
Width (mm): 1500
