- Código Máquina
- EX515
- Constructor
- WINDMÖLLER & HÖLSCHER
- Modello
- VAREX ( COEX )
- Año
- 2004
- Number of layers
- 3
- Film structure
- ABC
- Material
- LDPE , LLDPE
- Film Width
- 2200
- Output (Kg/h)
- 500
- Extruder 1 Layer ref:
- A
- Screw diam 1
- 60mm
- Description 1
- 30D . Gravimetric dosing unit 1+4 components
- Extruder 2 Layer ref:
- B
- Screw diam 2
- 90mm
- Description 2
- 30D. Gravimetric dosing unit 1+3 components
- Extruder 3 Layer ref:
- C
- Screw diam 3
- 60mm
- Description 3
- 30D. Gravimetric dosing unit 1+4 components
- Head description
- IBC . Optifil P 2. Multicool cooling system
- Die diam (mm)
- 450mm
- Thickness controll system
- Automatic Optifil P 2K with rotating measurement Kunding
- Bubble cage
- yes motorized
- Take off unit
- oscillating
- Corona treatment
- Softal
- Web guide
- BST
- Rewinder Type
- Double back to back
- Rewinder max reel diameter
- 800mm
- Rewinder description
- Double surface winder one upon another Filmatic T . Winding system central, contact and gap winding right an left winding possible. Winding with handling system. expansive shafts 76-152mm.
- Note
- Screenchanger manual. Calibrating basket with Ultrasonic Reversing haul off unit with long flatness unit. 5 knives (slitting unit) . Water cool system for bubble cooling Multicool cooling system Cutting station Vacuum station edge trimming Roll change device with chain Tower 50.000 Euro
| Código Máquina | EX515 |
| Constructor | WINDMÖLLER & HÖLSCHER |
| Modello | VAREX ( COEX ) |
| Año | 2004 |
| Number of layers | 3 |
| Film structure | ABC |
| Material | LDPE , LLDPE |
| Film Width | 2200 |
| Output (Kg/h) | 500 |
| Extruder 1 Layer ref: | A |
| Screw diam 1 | 60mm |
| Description 1 | 30D . Gravimetric dosing unit 1+4 components |
| Extruder 2 Layer ref: | B |
| Screw diam 2 | 90mm |
| Description 2 | 30D. Gravimetric dosing unit 1+3 components |
| Extruder 3 Layer ref: | C |
| Screw diam 3 | 60mm |
| Description 3 | 30D. Gravimetric dosing unit 1+4 components |
| Head description | IBC . Optifil P 2. Multicool cooling system |
| Die diam (mm) | 450mm |
| Thickness controll system | Automatic Optifil P 2K with rotating measurement Kunding |
| Bubble cage | yes motorized |
| Take off unit | oscillating |
| Corona treatment | Softal |
| Web guide | BST |
| Rewinder Type | Double back to back |
| Rewinder max reel diameter | 800mm |
| Rewinder description | Double surface winder one upon another Filmatic T . Winding system central, contact and gap winding right an left winding possible. Winding with handling system. expansive shafts 76-152mm. |
| Note | Screenchanger manual. Calibrating basket with Ultrasonic Reversing haul off unit with long flatness unit. 5 knives (slitting unit) . Water cool system for bubble cooling Multicool cooling system Cutting station Vacuum station edge trimming Roll change device with chain Tower 50.000 Euro |
