COMEXI ACOM RG Excel Maquina de grabado 6 colores

Código Máquina
RO254
Constructor
COMEXI ACOM
Modello
RG Excel
Año
2016
Number of colors
6
Print possibilities
6+0 , 5+1
Drive
Electronic shaft
Trolley system
Yes
Web width (mm)
1150
Print width (mm)
1100
Print repeat range (mm)
530 - 950
Drying specifications
Units 1- 5 : single drying hood 3,5 mt length ,1 blowing fan, 1 gas burner , 2 chill rollers- Unit 6 Double drying hood 2x 3, 5 mt length, 2 gas burners, 3 chill rollers .- Each unit with independent air recirculation system
Drying heat surce
gas burners
Unwinder type
Turret automatic
Max reel diameter unwinder (mm)
1200
Rewinder type
Turret automatic
Max reel diameter rewinder (mm)
1200
Register controll
Eltromat Registar 20
Note
Materials - Paper 40 - 120 gsm - Only water based inks Infeed driven nip section Outfeed driven nip section Web guides in and out Lay on pressur rollers sleeve based 165 mm diam
Código Máquina RO254
Constructor COMEXI ACOM
Modello RG Excel
Año 2016
Number of colors 6
Print possibilities 6+0 , 5+1
Drive Electronic shaft
Trolley system Yes
Web width (mm) 1150
Print width (mm) 1100
Print repeat range (mm) 530 - 950
Drying specifications Units 1- 5 : single drying hood 3,5 mt length ,1 blowing fan, 1 gas burner , 2 chill rollers- Unit 6 Double drying hood 2x 3, 5 mt length, 2 gas burners, 3 chill rollers .- Each unit with independent air recirculation system
Drying heat surce gas burners
Unwinder type Turret automatic
Max reel diameter unwinder (mm) 1200
Rewinder type Turret automatic
Max reel diameter rewinder (mm) 1200
Register controll Eltromat Registar 20
Note Materials - Paper 40 - 120 gsm - Only water based inks Infeed driven nip section Outfeed driven nip section Web guides in and out Lay on pressur rollers sleeve based 165 mm diam
