- Código Máquina
- FL1130
- Constructor
- FISCHER & KRECKE
- Modello
- F16 S
- Año
- 2001
- Number of colors
- 8
- Print possibilityes
- 8 + 1 Gravure Coating lamination unit + 1 Gravure coating in register
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1270
- Print width (mm)
- 1320
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 800
- Unwinder type
- Turret Automatic with roll loading system
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret Automatic with roll unloading system
- Max reel diameter rewinder (mm)
- 1000
- Drying
- CI section 2 zone s - 4 fans 5 mt tunnel - 1st Gravure unit 2 zones with 2 x 6 mt hoods totally 12 mt - 2nd Gravure coating unit 2 zones with 2 x 6 mt hoods totally 12 mt
- Videocamera
- Yes BST E LTROMAT new 2018
- Corona treatment
- 3 corona treaters driven
- Web guides
- 4 before print section and one before each gravure unit
- Vyscosity control
- Bloss Viscosity Control System Viscolor 2200
- Washing system
- Yes FK Autoclean
- Inking system
- Closed chamber doctor blades
- Anilox
- 18
- Print Sleeves
- 32
- Note
- Additional secondary Turret unwinder diam 1000 mm for lamination film
| Código Máquina | FL1130 |
| Constructor | FISCHER & KRECKE |
| Modello | F16 S |
| Año | 2001 |
| Number of colors | 8 |
| Print possibilityes | 8 + 1 Gravure Coating lamination unit + 1 Gravure coating in register |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1270 |
| Print width (mm) | 1320 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret Automatic with roll loading system |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret Automatic with roll unloading system |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | CI section 2 zone s - 4 fans 5 mt tunnel - 1st Gravure unit 2 zones with 2 x 6 mt hoods totally 12 mt - 2nd Gravure coating unit 2 zones with 2 x 6 mt hoods totally 12 mt |
| Videocamera | Yes BST E LTROMAT new 2018 |
| Corona treatment | 3 corona treaters driven |
| Web guides | 4 before print section and one before each gravure unit |
| Vyscosity control | Bloss Viscosity Control System Viscolor 2200 |
| Washing system | Yes FK Autoclean |
| Inking system | Closed chamber doctor blades |
| Anilox | 18 |
| Print Sleeves | 32 |
| Note | Additional secondary Turret unwinder diam 1000 mm for lamination film |
