- Código Máquina
- FL1122
- Constructor
- KBA FLEXOTECNICA
- Modello
- EVO XD
- Año
- 2017
- Number of colors
- 8
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1270
- Print width (mm)
- 1220
- Min print repeat (mm)
- 380
- Max print repeat (mm)
- 800
- Unwinder type
- Turret Automatic with roll loading system
- Rewinder type
- Turret Automatic with roll unloading system
- Drying
- 2 zones , 4 fans , final tunnel 5 mt length , 2 Gas Burners 200.000 Kcl/h each, Automatic Air recirculation system with LEL controls on each zone Zellweger
- Videocamera
- YES AVT 100% INSPECTION
- Web guides
- Yes in and out
- Vyscosity control
- yes GAMA
- Washing system
- Yes
- Anilox
- 12 ceramic anilox sleeves
- Print Sleeves
- approx 100
Código Máquina | FL1122 |
Constructor | KBA FLEXOTECNICA |
Modello | EVO XD |
Año | 2017 |
Number of colors | 8 |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1270 |
Print width (mm) | 1220 |
Min print repeat (mm) | 380 |
Max print repeat (mm) | 800 |
Unwinder type | Turret Automatic with roll loading system |
Rewinder type | Turret Automatic with roll unloading system |
Drying | 2 zones , 4 fans , final tunnel 5 mt length , 2 Gas Burners 200.000 Kcl/h each, Automatic Air recirculation system with LEL controls on each zone Zellweger |
Videocamera | YES AVT 100% INSPECTION |
Web guides | Yes in and out |
Vyscosity control | yes GAMA |
Washing system | Yes |
Anilox | 12 ceramic anilox sleeves |
Print Sleeves | approx 100 |
WINDMÖLLER & HÖLSCHER NOVOFLEX
-
Código Máquina: FL1059
-
Año: 2005
-
Web width (mm): 1320
UTECO ONYX 808
-
Código Máquina: FL1108
-
Año: 2011
-
Web width (mm): 1150
FISCHER & KRECKE 34DF/8 CNC
-
Código Máquina: FL0695
-
Año: 1995
-
Web width (mm): 1320
FLEXOTECNICA TACHYS
-
Código Máquina: FL1101
-
Año: 2003
-
Web width (mm): 1250
UTECO ONYX 808
-
Código Máquina: FL0937
-
Año: 2014
-
Web width (mm): 1300
UTECO DIAMOND HP 108
-
Código Máquina: FL1012
-
Año: 2009
-
Web width (mm): 1350
