- Código Máquina
- FL884
- Constructor
- WINDMÖLLER & HÖLSCHER
- Modello
- PRIMAFLEX
- Año
- 2003
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1070
- Print width (mm)
- 1020
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 760
- Unwinder type
- Turret Automatic
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret Automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones - 4 fans -Thermo oil heat exchangers
- Videocamera
- Yes BST
- Corona treatment
- Yes Softal
- Web guides
- Yes in and out
- Vyscosity control
- yes
- Inking system
- Closed chambe r doctor blades
- Anilox
- 12 Apex.
- Print Sleeves
- 17 sets from 30cm to 60cm
- Note
- Heating station for thermal oil
| Código Máquina | FL884 |
| Constructor | WINDMÖLLER & HÖLSCHER |
| Modello | PRIMAFLEX |
| Año | 2003 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1070 |
| Print width (mm) | 1020 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 760 |
| Unwinder type | Turret Automatic |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret Automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones - 4 fans -Thermo oil heat exchangers |
| Videocamera | Yes BST |
| Corona treatment | Yes Softal |
| Web guides | Yes in and out |
| Vyscosity control | yes |
| Inking system | Closed chambe r doctor blades |
| Anilox | 12 Apex. |
| Print Sleeves | 17 sets from 30cm to 60cm |
| Note | Heating station for thermal oil |
