A common application is Doypack, or stand up pouch. It is a sachet with a bottom fold and a particular outlay of stiffening welds which creates a modern and universal packaging that can stand up on its own. Other common applications are 3 side weld bags and stand up pouches with square bottoms.
Ask more informations
- Machine Code
- PO38
- Manufacturer
- WATERLINE
- Modello
- RITEBAG 1200-S-LP
- Year
- 2006
- Type of sealing/bags
- 3 side weld
- Bag length
- 150mm min 1200mm max
- Bag width
- 80mm min unlimited
- Unwinder
- Double W=1220mm x diameter 800mm on 152mm ID cores
- Additional information type of bags
- 3 side seal pouches
- Note
- Installed power 70Kw, 400V 50 Hz 14 m x 2 m x 2.3 m (L x W x H) 2 edge ultrasensor edge guides 2 longitudinal sealing stations, with 4 bars and 5 bars 600+ 600mm cooling 4 cross sealing bars 2 cross cooling bars 8 Euro holes, 9 Round corner, 9 tear notch punching units cross cutting station with servo-drive Guillotine mounted on ball rails Nr. 1 Industrial-PC with VGA graphic monitor and touch screen 12" (800 x 600 pixel)
| Machine Code | PO38 |
| Manufacturer | WATERLINE |
| Modello | RITEBAG 1200-S-LP |
| Year | 2006 |
| Type of sealing/bags | 3 side weld |
| Bag length | 150mm min 1200mm max |
| Bag width | 80mm min unlimited |
| Unwinder | Double W=1220mm x diameter 800mm on 152mm ID cores |
| Additional information type of bags | 3 side seal pouches |
| Note | Installed power 70Kw, 400V 50 Hz 14 m x 2 m x 2.3 m (L x W x H) 2 edge ultrasensor edge guides 2 longitudinal sealing stations, with 4 bars and 5 bars 600+ 600mm cooling 4 cross sealing bars 2 cross cooling bars 8 Euro holes, 9 Round corner, 9 tear notch punching units cross cutting station with servo-drive Guillotine mounted on ball rails Nr. 1 Industrial-PC with VGA graphic monitor and touch screen 12" (800 x 600 pixel) |
ELBA SAV20-12
-
Machine Code: PO61
-
Year: 2008
-
Bag width: 120 - 1200 mm
LECHITA S65/AUT
-
Machine Code: PO67
-
Year: 2010
-
Bag width: max 650mm
HUDSON SHARP HS750SUP
-
Machine Code: PO32
-
Year: 2004
-
Bag width: max 600mm
