POLYTYPE POLYTYPE 522 Laminator / coating machine SOLVENTLESS // Laminators and coaters // Converting machines // Used Flexo Press // Tecno Converting 2000 S.r.l.

These employ an interchangeable trolley system which allows different types of coatings or laminations depending on available trolleys.

Photo Gallery

Ask more informations

Machine Code: LA348
Manufacturer: POLYTYPE
Modello: POLYTYPE 522
Year: 1982
Application: Coating
Type of lamination/coating: SOLVENTLESS
Overhaul/renovation: 2003
Working width (mm): 1040
Materials: Paper, PET, PA, OPS, OPP,Aluminium
Speed: 300 m/min
First unwinder type: Single
Max diameter reel unwinder: 1000
Secondary unwinder type: Single
Max diameter reel unwinder: 1000
Rewinder type: Turret
Coating unit: 5 roller for solventless
Corona treatment: 1 SOFTAL Model: 8040 de 5KVA 16A
Note: PLC Siemens S7: 315 2DP (315-2AF03-0AB0) Touch screen: Panel TP270 TOUCH 10” (6AV6 545-0CC10-0AX0) 6 Drivers: PARKER 590P 40 1 Driver: PARKER 690P 5,5 kw Corona Threaters: 1 SOFTAL Model: 8040 de 5KVA 16A 1 FERRARINI & BENELL1 Model: GTS10 de 26A Web aligners: 2 Aligners FIFE Model: P50 – 1F 22 TA

Machine Code	LA348
Manufacturer	POLYTYPE
Modello	POLYTYPE 522
Year	1982
Application	Coating
Type of lamination/coating	SOLVENTLESS
Overhaul/renovation	2003
Working width (mm)	1040
Materials	Paper, PET, PA, OPS, OPP,Aluminium
Speed	300 m/min
First unwinder type	Single
Max diameter reel unwinder	1000
Secondary unwinder type	Single
Max diameter reel unwinder	1000
Rewinder type	Turret
Coating unit	5 roller for solventless
Corona treatment	1 SOFTAL Model: 8040 de 5KVA 16A
Note	PLC Siemens S7: 315 2DP (315-2AF03-0AB0) Touch screen: Panel TP270 TOUCH 10” (6AV6 545-0CC10-0AX0) 6 Drivers: PARKER 590P 40 1 Driver: PARKER 690P 5,5 kw Corona Threaters: 1 SOFTAL Model: 8040 de 5KVA 16A 1 FERRARINI & BENELL1 Model: GTS10 de 26A Web aligners: 2 Aligners FIFE Model: P50 – 1F 22 TA
