** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL1111
- Manufacturer
- FLEXOTECNICA
- Modello
- FG8
- Year
- 2005
- Number of colors
- 9
- Print possibilityes
- 8 on CI +1 STACK DOWNSTREAM
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1350
- Print width (mm)
- 1300
- Min print repeat (mm)
- 400
- Max print repeat (mm)
- 1200
- Unwinder type
- Turret automatic
- Max reel diameter unwinder (mm)
- 1270
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 1270
- Drying
- 2 zones , 4 fans, final tunnel 2 gas burners - Downstream stack unit with Drying hood and UV drying box
- Videocamera
- yes
- Corona treatment
- YES
- Web guides
- yes in and out Fife OPG
- Vyscosity control
- yes 8
- Washing system
- yes on CI section
- Inking system
- Closed chamber doctor blades and ceramic anilox - totally 11 blade chabers and 11 pumps with tanks
- Anilox
- 27 ceramic anilox sleeves 1x50/30, 1x50x25, 1x90x19, 1x100/15, 2x120/12, 3x140/12, 1x140/8, 1x180/9, 1x180/7, 3x220/6.5, 2x32/5.5, 1x420/38, 2x420/48, 1x460/3.2, 5x460/3.2
- Print Sleeves
- 190 print sleeves
- Note
- Turning Bar 8+8 half width Chiller Corema
| Machine Code | FL1111 |
| Manufacturer | FLEXOTECNICA |
| Modello | FG8 |
| Year | 2005 |
| Number of colors | 9 |
| Print possibilityes | 8 on CI +1 STACK DOWNSTREAM |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1350 |
| Print width (mm) | 1300 |
| Min print repeat (mm) | 400 |
| Max print repeat (mm) | 1200 |
| Unwinder type | Turret automatic |
| Max reel diameter unwinder (mm) | 1270 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 1270 |
| Drying | 2 zones , 4 fans, final tunnel 2 gas burners - Downstream stack unit with Drying hood and UV drying box |
| Videocamera | yes |
| Corona treatment | YES |
| Web guides | yes in and out Fife OPG |
| Vyscosity control | yes 8 |
| Washing system | yes on CI section |
| Inking system | Closed chamber doctor blades and ceramic anilox - totally 11 blade chabers and 11 pumps with tanks |
| Anilox | 27 ceramic anilox sleeves 1x50/30, 1x50x25, 1x90x19, 1x100/15, 2x120/12, 3x140/12, 1x140/8, 1x180/9, 1x180/7, 3x220/6.5, 2x32/5.5, 1x420/38, 2x420/48, 1x460/3.2, 5x460/3.2 |
| Print Sleeves | 190 print sleeves |
| Note | Turning Bar 8+8 half width Chiller Corema |
