Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
- Machine Code
- FL1098
- Manufacturer
- COMIFLEX
- Modello
- CI8
- Year
- 2006
- Number of colors
- 8
- Overhaul/renovation
- mechanical and software upgrading in 2013
- Gearless
- No
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1280
- Print width (mm)
- 1200
- Min print repeat (mm)
- 340
- Max print repeat (mm)
- 800
- Unwinder type
- Double bracket
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Double automatic turret rewinder
- Max reel diameter rewinder (mm)
- 800
- Drying
- two separate stations for drying with electric resistance, drum and drying tube
- Videocamera
- Yes
- Web guides
- Yes, IN and OUT
- Anilox
- 15 Anilox
- Note
- mechanical speed 300m/min Cast iron frame 120mm thickness CI diam 1700mm double walls type clishe 1,14mm
| Machine Code | FL1098 |
| Manufacturer | COMIFLEX |
| Modello | CI8 |
| Year | 2006 |
| Number of colors | 8 |
| Overhaul/renovation | mechanical and software upgrading in 2013 |
| Gearless | No |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1280 |
| Print width (mm) | 1200 |
| Min print repeat (mm) | 340 |
| Max print repeat (mm) | 800 |
| Unwinder type | Double bracket |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Double automatic turret rewinder |
| Max reel diameter rewinder (mm) | 800 |
| Drying | two separate stations for drying with electric resistance, drum and drying tube |
| Videocamera | Yes |
| Web guides | Yes, IN and OUT |
| Anilox | 15 Anilox |
| Note | mechanical speed 300m/min Cast iron frame 120mm thickness CI diam 1700mm double walls type clishe 1,14mm |
