UTECO DIAMOND HP 108 flexo printing machine 10 colors

Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".

Ask more informations
Machine Code
FL1012
Manufacturer
UTECO
Modello
DIAMOND HP 108
Year
2009
Number of colors
10
Print possibilityes
10+0
Gearless
Yes
Fast sleeve change
Yes
4 motor per deck CNC position system
Yes
Computer supervision
Yes
Web width (mm)
1350
Print width (mm)
1300
Min print repeat (mm)
400
Max print repeat (mm)
850
Unwinder type
Turret Automatic non stop
Max reel diameter unwinder (mm)
1000
Rewinder type
Turret Automatic non stop
Max reel diameter rewinder (mm)
1000
Drying
2 zones , 4 fans , double tunnel 2x 3 mt , 2 gas burners . Automatic air recirculation system with LEL control
Videocamera
Yes BST
Corona treatment
Yes driven
Web guides
Yes in and out
Vyscosity control
Yes
Washing system
YES
Inking system
Closed chamber doctor blades
Anilox
15 ceramic anilox sleeves
Machine Code FL1012
Manufacturer UTECO
Modello DIAMOND HP 108
Year 2009
Number of colors 10
Print possibilityes 10+0
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1350
Print width (mm) 1300
Min print repeat (mm) 400
Max print repeat (mm) 850
Unwinder type Turret Automatic non stop
Max reel diameter unwinder (mm) 1000
Rewinder type Turret Automatic non stop
Max reel diameter rewinder (mm) 1000
Drying 2 zones , 4 fans , double tunnel 2x 3 mt , 2 gas burners . Automatic air recirculation system with LEL control
Videocamera Yes BST
Corona treatment Yes driven
Web guides Yes in and out
Vyscosity control Yes
Washing system YES
Inking system Closed chamber doctor blades
Anilox 15 ceramic anilox sleeves
