** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL732
- Manufacturer
- UTECO
- Modello
- TOPAZ 608 GL MOD 160
- Year
- 2014
- Number of colors
- 6
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1650
- Print width (mm)
- 1600
- Min print repeat (mm)
- 450
- Max print repeat (mm)
- 850
- Unwinder type
- Single
- Max reel diameter unwinder (mm)
- 1500
- Rewinder type
- Turret
- Max reel diameter rewinder (mm)
- 1000
- Drying
- Gas burners. Tunnel 4 mt long. Motorized air recirculation system with LEL system
- Videocamera
- Grafikscan 2200 with Click & Drag
- Web guides
- OPG at web infeed . Spreader roll MINK type
- Washing system
- Yes
- Inking system
- 6 closed chamber doctor blades; 6 ink pumps; solvent based and water based inks
- Anilox
- 6
- Print Sleeves
- 500
- Note
- Machine installed end of 2014 and started in beginning 2015 Mechanical speed :up to 300 m/min max Material:paper 50-150 g/m2 Single shaft unwinder “SAC-N-U-1500” Rewinder type TAR-N-1000 Spreader rollers MINK type
| Machine Code | FL732 |
| Manufacturer | UTECO |
| Modello | TOPAZ 608 GL MOD 160 |
| Year | 2014 |
| Number of colors | 6 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1650 |
| Print width (mm) | 1600 |
| Min print repeat (mm) | 450 |
| Max print repeat (mm) | 850 |
| Unwinder type | Single |
| Max reel diameter unwinder (mm) | 1500 |
| Rewinder type | Turret |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | Gas burners. Tunnel 4 mt long. Motorized air recirculation system with LEL system |
| Videocamera | Grafikscan 2200 with Click & Drag |
| Web guides | OPG at web infeed . Spreader roll MINK type |
| Washing system | Yes |
| Inking system | 6 closed chamber doctor blades; 6 ink pumps; solvent based and water based inks |
| Anilox | 6 |
| Print Sleeves | 500 |
| Note | Machine installed end of 2014 and started in beginning 2015 Mechanical speed :up to 300 m/min max Material:paper 50-150 g/m2 Single shaft unwinder “SAC-N-U-1500” Rewinder type TAR-N-1000 Spreader rollers MINK type |
