Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.
Ask more informations
- Machine Code
- FL0715
- Manufacturer
- PCMC
- Modello
- VISION G
- Year
- 2005
- Number of colors
- 8
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1000
- Print width (mm)
- 900
- Min print repeat (mm)
- 320
- Max print repeat (mm)
- 630
- Unwinder type
- TURRET AUTOMATIC
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- TURRET AUTOMATIC
- Max reel diameter rewinder (mm)
- 800
- Drying
- Electric drying system with compressed air(dedicated compressor) and LEL
- Videocamera
- AVT PRINT VISION JUPITER
- Corona treatment
- ENERCON
- Web guides
- BST
- Anilox
- 19 ceramic anilox: 1 x 80, 2 x 100, 2 x 120, 2 x 175, 2 x 240, 8 x 315, 2 x 340
- Note
- Complete PLC automatic control of all printing parameters Automatic positioning of printing groups Quick sleeves change system
| Machine Code | FL0715 |
| Manufacturer | PCMC |
| Modello | VISION G |
| Year | 2005 |
| Number of colors | 8 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1000 |
| Print width (mm) | 900 |
| Min print repeat (mm) | 320 |
| Max print repeat (mm) | 630 |
| Unwinder type | TURRET AUTOMATIC |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | TURRET AUTOMATIC |
| Max reel diameter rewinder (mm) | 800 |
| Drying | Electric drying system with compressed air(dedicated compressor) and LEL |
| Videocamera | AVT PRINT VISION JUPITER |
| Corona treatment | ENERCON |
| Web guides | BST |
| Anilox | 19 ceramic anilox: 1 x 80, 2 x 100, 2 x 120, 2 x 175, 2 x 240, 8 x 315, 2 x 340 |
| Note | Complete PLC automatic control of all printing parameters Automatic positioning of printing groups Quick sleeves change system |
