** SOLD **
Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.
Ask more informations
about a similar one
- Machine Code
- FL759
- Manufacturer
- UTECO
- Modello
- CORAL 675
- Year
- 1995
- Number of colors
- 6
- Print possibilityes
- 6+0
- Gearless
- No
- Fast sleeve change
- No
- 4 motor per deck CNC position system
- Not specifed
- Computer supervision
- Yes
- Web width (mm)
- 820
- Print width (mm)
- 800
- Min print repeat (mm)
- 300
- Max print repeat (mm)
- 750
- Unwinder type
- Two position unwidner , drop splice
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Two position independent rewinder
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones , 4 fans, 3 mt tunnel electric heaters
- Videocamera
- yes BST Super Handy Scan
- Web guides
- yes
- Inking system
- Closed chamber doctor blades
- Anilox
- 12 ceramic as follows : 3 x280 l/ cm vol.5,6 ; 2 x280 l/cm vol 8,0 HVP; 2 x240 l/cm vol 6,0; 2 x120 l/cm vol8,0; 1 x120 l/cm vol12,5; 1 x 160 l/cm vol.12,5; 1 x 100 l/cm
- Print Sleeves
- 115 print sleeves ; 1 set of mandrels, 3 sets of adaptors sleeves as follows : 6 x 299 mm; 6 x 319 ; 6 x334 ; 6 x 364 ; 6 x 384 ; 6 x 404 ; 6 x 429 ; 6 x 449 ; 6 x 469 ; 6 x 489 ; 6 x 509 ; 6 x 529 ; 6 x 553,6 ; 6 x 573,5 ; 6 x 603,5 ; 6 x 638,4 ; 6 x 683,3
- Note
- Motorized print deck prepositioning Motorized longitudinal registers Sleeve change on trolley out of machine Gear pitch DP 16
| Machine Code | FL759 |
| Manufacturer | UTECO |
| Modello | CORAL 675 |
| Year | 1995 |
| Number of colors | 6 |
| Print possibilityes | 6+0 |
| Gearless | No |
| Fast sleeve change | No |
| 4 motor per deck CNC position system | Not specifed |
| Computer supervision | Yes |
| Web width (mm) | 820 |
| Print width (mm) | 800 |
| Min print repeat (mm) | 300 |
| Max print repeat (mm) | 750 |
| Unwinder type | Two position unwidner , drop splice |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Two position independent rewinder |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones , 4 fans, 3 mt tunnel electric heaters |
| Videocamera | yes BST Super Handy Scan |
| Web guides | yes |
| Inking system | Closed chamber doctor blades |
| Anilox | 12 ceramic as follows : 3 x280 l/ cm vol.5,6 ; 2 x280 l/cm vol 8,0 HVP; 2 x240 l/cm vol 6,0; 2 x120 l/cm vol8,0; 1 x120 l/cm vol12,5; 1 x 160 l/cm vol.12,5; 1 x 100 l/cm |
| Print Sleeves | 115 print sleeves ; 1 set of mandrels, 3 sets of adaptors sleeves as follows : 6 x 299 mm; 6 x 319 ; 6 x334 ; 6 x 364 ; 6 x 384 ; 6 x 404 ; 6 x 429 ; 6 x 449 ; 6 x 469 ; 6 x 489 ; 6 x 509 ; 6 x 529 ; 6 x 553,6 ; 6 x 573,5 ; 6 x 603,5 ; 6 x 638,4 ; 6 x 683,3 |
| Note | Motorized print deck prepositioning Motorized longitudinal registers Sleeve change on trolley out of machine Gear pitch DP 16 |
