** SOLD **

Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.

Photo Gallery

Ask more informations

about a similar one

Machine Code: FL691
Manufacturer: COMEXI
Modello: FW1508
Year: 2008
Number of colors: 8
Print possibilityes: 8+0
Gearless: Yes
Fast sleeve change: Yes
4 motor per deck CNC position system: Yes
Computer supervision: Yes
Web width (mm): 1270
Print width (mm): 1220
Min print repeat (mm): 350
Max print repeat (mm): 800
Unwinder type: turret automatic
Max reel diameter unwinder (mm): 800
Rewinder type: turret automatic
Max reel diameter rewinder (mm): 800
Drying: 2 zones four fans , two gas burners
Videocamera: 1 AVT
Web guides: 1 before rewind, 1 before printing
Vyscosity control: yes automatic
Washing system: Automatic washing
Inking system: closed chamber doctor blades
Anilox: 17 (6x400 l/cm , 2x360, 1x320, 1x300, 2x280, 2x200, 2x160, 3x100)
Print Sleeves: 70
